Commercial Flagpole Types

ESS - External Single Stationary Poles

This flagpole group os one of our more simple builds, but still offers amazing stability for your flagpole display! Check out the main components below! The ESS Poles offer commercial-grade flagpoles designed for budget-conscious projects without compromising on quality. These flagpoles are available in heights from 15' to 35', making them an excellent choice for residential homes, small businesses, and some commercial complexes.

The key features are:

• Patented heavy-duty gold anodized aluminum ball for durability
• Cast aluminum single stationary truck with an aluminum pulley for easy flag hoisting
• External halyard system with 5/16" polyester rope for secure flag attachment
• Two nickel-plated cast zinc swivel flag-snaps and neoprene covers
• 9" cast aluminum cleat for easy flag adjustment
• Spun aluminum FC-11 flash collar for a polished finish
• PVC ground sleeve for secure installation

ESR - External Single Revolving Poles

Take all the best qualities of the ESS flagpoles above and add a revolving truck at the top... and additional height options! The heavy-duty aluminum flagpoles are available in heights from 20' to 80', paired with the highest quality hardware in the industry. These flagpoles are designed to meet stringent architectural standards, making them an ideal choice to enhance the landscape of any business or industrial property.

The key features are:

• Cast aluminum revolving truck with dual stainless steel bearings and aluminum pulley for smooth operation
• External halyard system with 5/16" polyester rope for secure flag handling
• Solid brass swivel flag-snaps with neoprene covers for reliable performance
• 9" cast aluminum cleat for easy flag adjustment
• Spun aluminum FC-11 flash collar for a refined finish
• Galvanized 16-gauge corrugated steel ground sleeve with steel grounding spike for stable installation

XESR - Extreme External Single Revolving Poles

Everything you know and love about our traditional ESR poles, but better! Offering improved wind grading, these poles will stand up to the most windy locations in the world! You can choose between many options including heights between 25-70' and 8 color choices.

The key features are:

• Dual-sealed, cast aluminum revolving truck with dual stainless steel bearings and aluminum pulley for smooth operation
• External halyard system with 3/8" polyester rope for secure flag handling
• Solid brass swivel flag-snaps with neoprene covers for reliable performance
• 9" cast aluminum cleat for easy flag adjustment
• Spun aluminum FC-11 flash collar for a refined finish
• Galvanized 16-gauge corrugated steel ground sleeve with steel grounding spike for stable installation

ICC - Internal Cam-Cleat Poles

If you want a pole that looks clean on the outside and requires a key to manipulate the flag placement on the pole, then this could be the pole for you. Using a strong Cam-Cleat to lock the halyard in place, this style pole is a step above the external halyard poles you saw above! These flagpoles ensure 24/7 security thanks to a concealed halyard and lockable flush-mount hinged door!

The key features are:

• Durable, patented heavy-duty gold anodized aluminum ball
• Cast aluminum revolving truck with sealed stainless steel bearings for smooth rotation
• Internal halyard system with a 5/16" wire center polyester rope
• Cam cleat mechanism for easy flag management
• Lockable flush-mount door with keys for enhanced security
• Galvanized steel ground sleeve with grounding spike for stable installation

ISC - Reinforced Internal Cam-Cleat Poles

With the same internal mechanism as the ICC poles, the reinforced ISC pole version features an upgraded, raised door frame section and is available in sizes between 20' and 40'. These poles come equipped with everything you need to start flying your flag from the get-go!

The key features are:

• A lasting gold anodized aluminum ball - Patent protected
• Cast aluminum revolving truck with sealed stainless steel bearings
• Internal halyard system featuring a 5/16" wire center polyester rope
• Cam cleat mechanism for easy flag adjustment
• Reinforced raised door frame for added resilience
• Secure flush-mount door with locking mechanism and keys
• Sturdy galvanized steel ground sleeve with a grounding spike for stability

IRC - Reinforced Welded Cam-Cleat Poles

Just like our other internal Cam-Cleats, The IRC pole series is an ideal choice for projects that require a commercial-grade flagpole! The major difference between others and the IRC poles is the precision mounted welded Door frame. This gives the pole a smooth finish and is our highest level Cam-Cleat pole option!

The key features are:

• The Patented pole ornamental topper
• Cast aluminum revolving truck with sealed stainless steel bearing assemblies
• Complete halyard assembly with 5/16" #10 wire center polyester rope
• Secure Cam-Cleat holding system for secure flag attachment
• Lockable flush-mount access door with keys
• Galvanized steel ground sleeve with a steel grounding spike for stability

IWW - Internal Wire Halyard Poles With Winch Assembly

The Titan Series offers robust, commercial-grade flagpoles equipped with an Internal Halyard Winch and Wire Cable system for enhanced security. Available in heights from 20' to 80', these flagpoles provide peace of mind with a concealed halyard and a lockable, flush-mount hinged door, ensuring 24/7 security for your flag display.

The key features are:

• Patented heavy-duty gold anodized aluminum ball
• Cast aluminum revolving truck with dual sealed stainless steel bearing assemblies
• Internal halyard system with wire halyard and stainless steel winch with removable hand crank
• Flush mount access door with lock and keys for added security
• Galvanized steel ground sleeve with a steel grounding spike for stability (see photos)

ISW - Reinforced Internal Wire Halyard Poles With Winch Assembly

The Internal Winch Series also totes the ISW poles! They feature flagpoles with butt diameters ranging from 5" to 7" and heights between 20' and 40', designed for areas with moderate wind speeds. Its raised reinforced door frame combines the security of an Internal Halyard Winch and Wire Cable system with the strength needed for durability in challenging conditions.

The key features are:

• The Patented heavy-duty gold anodized aluminum ball
• Cast aluminum revolving truck with dual sealed stainless steel bearing assemblies
• Complete internal halyard system with wire halyard cable assembly
• A removable hand crank for the stainless steel winch
• Reinforced raised door frame with two tamper-proof screws for added security
• Galvanized steel ground sleeve with a steel grounding spike for stability

IRW - Reinforced Welded Cam-Cleat Poles

The internal winch series offers commercial-grade flagpoles featuring a heavy-duty internal halyard winch and wire cable system. Available in heights from 20' to 80', these flagpoles are engineered with a reinforced welded door frame that enhances both strength and security. The lockable flush-mount door provides a sleek, polished appearance, making this series a superior choice for various commercial applications.

The key features are:

• A Beautiful gold anodized aluminum ball - Patented
• Sealed stainless steel bearing assemblies in a flawless cast aluminum revolving truck
• Completely revamped internal halyard system, equipped with wire halyard cable assembly
• Lockable flush-mount access door with keys for the reinforced welded door frame
• Galvanized steel ground sleeve with a steel grounding spike for added stability
